PS46-FANCOIL-EU

Akubela HyPanel Lite 6

HyPanel Lite 6 — New hassle-free smart control panel for your home

The Akubela HyPanel Lite 6 (PS46-FANCOIL-EU) is a Linux-based smart home centre panel with a 4-inch multi-touch screen. Its all-in-one design brings together smart intercom, a Zigbee 3.0 gateway and home automation, with a built-in IR controller, environmental sensors and relays for fan-coil climate control, so one panel can replace several separate controllers.

4-inch

Multi-touch Screen

Zigbee 3.0

Gateway

Smart

Intercom

IR & Fan Coil

Climate Control

Download Datasheet Request a Quote

Technical Features

Built for Simplified Smart Home Control

The Akubela HyPanel Lite 6 runs on a stable Linux platform and brings intercom, Zigbee and climate control together in one compact panel.

All-in-One Smart Home Centre

Smart intercom, Zigbee gateway and home automation combined in one panel, replacing multiple controllers

4″ Multi-Touch Screen

480 × 480 display at 210 cd/m² with energy saving mode, plus 2 touch buttons for the whole family

Zigbee 3.0, Wi-Fi & RS485

Zigbee 3.0 gateway for up to 32 sub-devices, Wi-Fi 802.11 b/g/n/ax at 2.4GHz and an RS485 port

Fan Coil Climate Control

5 built-in relays: 3 for fan speed and 2 for cooling/heating valves, with NTC input accurate to ±0.5°C

Built-in IR & Sensors

IR controller (90° × 90°, 6m) plus proximity, light, temperature and humidity sensors

Smart Intercom

Dual microphones and a 1.5W speaker let residents answer visitor calls and unlock doors from the panel

Frequently Asked Questions

Akubela HyPanel Lite 6 — Common Questions

Everything you need to know about the Akubela HyPanel Lite 6 before you buy.

What is the Akubela HyPanel Lite 6?

What connectivity does the HyPanel Lite 6 support?

The HyPanel Lite 6 supports Wi-Fi (IEEE 802.11 b/g/n/ax at 2.4GHz), Zigbee 3.0 with up to 32 Zigbee sub-devices, a built-in IR controller (90° horizontal and vertical, 6m range) and an RS485 port.

Can the HyPanel Lite 6 control fan coil air conditioning?

Yes. The PS46-FANCOIL-EU has 5 built-in relays: 3 for fan speed and 2 for the cooling and heating valves. Each relay handles resistive loads up to 5A and inductive loads up to 3A, with fan relay capacity of 5A and valve relay capacity of 6A. An NTC input measures -30°C to 80°C with ±0.5°C accuracy.

Which sensors are built into the HyPanel Lite 6?

It has a proximity sensor (30–60cm), a light sensor, a temperature sensor (±1°C, -10°C to 55°C) and a humidity sensor (±5%, 10% to 90%RH), so lighting, shades and climate can react to the room automatically.

How is the HyPanel Lite 6 installed?

The HyPanel Lite 6 is wall flush mounted on a standard EU or US flush mounting box and runs on 100–240VAC, 50/60Hz. It is rated IP20 for indoor use, with a working temperature of -10°C to +55°C.

Where can I buy the Akubela HyPanel Lite 6 in India?

The Akubela HyPanel Lite 6 is available in India through Cohesive Technologies, the authorized Akubela distributor for India, Sri Lanka, Nepal and the Maldives. Email sales@cohesiveglobal.com or call +91 120 4830000.
